SMUC30 (Booster 24-24 50A) Motion

Dostępność: dostępny na zamówienie
Wysyłka w: do ustalenia
Cena: 3 324,00 zł 3324.00
Cena netto: 2 702,44 zł
ilość szt.
Ocena: 0
Producent: WhisperPower
Kod produktu: 60110065
Nr producenta: 60110065

Opis

INPUT
Input range, full output specifications 10,5..17 VDC / 21..32 VDC *
Input range 9..18 VDC / 9..32 VDC*
OUTPUT
Nominal output voltage 14,4 VDC / 28,8 VDC*
Voltage adjustment None
Output voltage ripple, peak 1%
Maximum output current 50 A / 30 A**
Continuous output current at 40ºC 50 A
GENERAL
Efficiency >93%
No load consumption <80 mA
Ambient operating temperature -10°C .. + 40°C, de-rating to + 60°C
Storage temperature -25°C .. + 85°C
Operating humidity 95% max, non-condensing
Galvanic insulation Common negative
Cooling fan No
PROTECTIONS
Overcurrent / short circuit Yes / fuse
Over heat, shutdown Limited power by temperature sensor
MECHANICAL SPECIFICATIONS
Connections input/output, brass stips 8 mm2
Enclosure Dimensions (H*W*D) 64 x 355 x 163 mm
Weight 2.25 kg
